Brooks Instrument is a company of highly trained specialists with 70 years of experience in development and manufacturing of flow meters.
We are the global leader in precision fluid measurement and control technology and enable precision process performance. We deliver results that consistently create a competitive advantage for our customers. In heavy industry. In oil and gas refining. Chemical and petrochemical research. Pharmaceutical and biopharmaceutical production. Solar cell, LED, thin film, fiber optic and semiconductor manufacturing.
Brooks Instrument has manufacturing locations, sales and service offices in the Americas, Europe, Middle East and Asia. Global Headquarters is based in Pennsylvania – USA.
Brooks Instrument provides a global service network via representatives and distributors.
Product Portfolio
Brooks Instrument’s portfolio includes Metal Tube Variable Area (VA) flow meters, Glass Tube Variable Area (A) flow meters, Thermal Mass Flow controllers and meters, Coriolis Mass Flow controllers and meters, Pressure controllers and regulators, Vacuum Capacitance Manometers and a variety of flow accessories.
ITW
Brooks Instrument is a division of ITW (Illinois Tool Works), a Fortune 200 company. ITW is one of the world’s leading diversified manufacturers of specialized industrial equipment, consumables and related service businesses.
The company has prospered for over 100 years because each of ITW’s businesses has an independent entrepreneurial spirit and freedom to innovate. It’s the highly talented people at ITW all over the world who drive our success through new products and customer-driven solutions.
For more information on flow solutions, products, or sales contacts please visit www.BrooksInstrument.com.
