Flowmeister represents FlowMax® instruments, developed and manufactured by the German company MIB GmbH.
Key-area is the segment of Single Use (aseptic) applications in bio-pharmacy worldwide.
The second branche is high-tech OEM where we meet high demands for reliability in cooling-circuits.
The Flowmax® plastic instruments apply ultrasonic measuring technology and are mounted inline.
Low cost and high chemical resistance are established with body-materials like HDPE+, POM, PP, PFA, PSU and others on demand.
Inherent to the ultrasonic measuring principle, a fast, accurate and repeatable measurement brings excellent results in pulsating flow and even reverse-flow.
All instruments can be ordered with three- or eight-point calibration certificate.
Flowmax® 242i generation 3.0 moulded version per Q1 2023
Flowmax® is a multiparameter instrument, it brings:
– Flowrate
– Air bubble / empty pipe detection
– Self-teaching teaching new liquids
– Liquid identification and property monitoring by actual speed of sound
– Flow limit-switch
– Totalizer
– Temperature reading
– Standard analogue, pulse- and RS485-output
– Flow-control solutions available
– Flowrange from 5 ml/minute up to 900 l/minute
Flowmax® 242i is the Single Use design flowmeter, with permanent electronics and a disposable measuring tube.
This brings the highest level of cleanliness and contamination-control in your process.
The calibrated measuring tubes stand for flexibility, different bore-sizes can easily be swapped without compromises to accuracy.
An interesting investigation: modelled, performed and documented by ReGEN Biomedical Findings are in line with Comsol modelling and our R&D models. To receive a copy, leave a comment or DM Ron van Dooren with ‘whitepaper’. [Picture source: Flowmeister B.V. on linkedin.com]
Single-Use Technology (SUT) has helped streamline processes by: * reducing contamination risks, * simplifying cleaning, * minimizing the chance of product loss.
These disposable technologies improve efficiency by shortening manufacturing times and eliminating the need for in-house sterilization of equipment. Read more [Picture source: Flowmeister B.V. on linkedin.com]
Our compliments to our American partner AlphaBio for featuring Flowmax® 242i Single Use flowmeter !! The key-benefits are well described in this short animation. [Source: Ron van Dooren on youtube.com]
A) Flowmeister has a giant ball-point pen B) a neat and narrow-footprint Flowmax 242i Single Use flow measurement tube. Note the straight line beteen inlet and outlet Triclamp connection. Read more
Did you know that our Single USe flowmeter Flowmax® 242i has all these features, just like the industrial and chemical product-ranges of Flowmax? Developed, produced and calibrated by MIB GmbH. [Picture source: Flowmeister B.V. on linkedin.com]
ACHEMA 2024 was a great next step in tightening the co-operation between MIB Ultrasonic Flowmeasurement and Flowmeister B.V.. The Flowmax®242i Generation 3 is literally our ‘baby’ and we take good care of it 😉 Proudly wearing the MIB-badge, and equally proud of the establishment of Flowmeister as MIB’s branchemanager Single Use. [Picture source: Flowmeister B.V. on linkedin.com]
Many of us can measure flow, few of us have a true plug-and-play solution. Flowmax 242i is the only Single Use measuring tube with integrated Calibration data, ensuring highest possible reproducibility. Read more [Picture source: Flowmeister B.V. on linkedin.com]
Innovative, accurate, versatile, pressure-independent. Q-dose systems for a wide range of flowcontrol, from fast shot-dose to stable flow in dynamic circumstances. Available in Single Use, Chemical and Industrial versions. Check your application-ideas at Info@flowmeister.nl
Inside the Flowmax® 242i Single Use measuring-tube of course! We’re proud to introduce the generation 3.0 in moulded LDPE soon! Each instrument is calibrated and carries the data safely embedded, Gamma-stable!
The answer is: “YES we can!” Here are some tips regarding the customizable outputsignal. An additional advise: verify that your medium is suitable for ultrasonic flowmeasurement, there are exceptions, we know 😉
Some hose-types don’t allow clamp-on flowmeter, e.g. fiberinforced materials. Our inline solution isn’t sensitive to that and will succesfully measure flow through special medical tubing. Read more
When developing Flowmax®, MIB GmbH has prioritized one key element: reliability. An instrument’s reliability depends on several factors, in this blog we explain how MIB „has optimized Flowmax®-design for a lifetime of accurate measurements. Read more
Liquid flowmeasurement is interesting, but it’s often just half the solution. Most applications which require a flowmeter are using the flowmeasurement to control the process. Flowmeister strives to deliver maximum value to you. A good example of such value is the trust you experience when your process is running well under a steady flowcontrol solution. Read more [Source: fluidhandlingpro.com]
All Flowmax-instruments calculate the volume-flow of liquids with ultrasonic technology. Each Flowmax is able to measure conductive and non-conductive liquids in a contact-free way. There is only one wetted part, the measuring-tube itself. he most versatile member of the family is Flowmax 42i. Read more [Source: fluidhandlingpro.com]
To be honest, when we would be having a conversation about your application, it doesn’t matter wether the needed instrument is referred to as flowmeter or flow sensor. We will both know what we mean and come to the right conclusion. A different situation is the moment that an engineer starts searching the internet for a flow sensor. Chances are high that the search result returns a sensor which has no proper measuring capability. A disappointing testresult is to be expected. Read more
When asked what is the most important property of flow measurement, almost every customer answers “ACCURACY”. Understandable, you would rather not invest in an inaccurate instrument to control your pocess. When the conversation continues, very often it appears that the automated production system is not too dependent on accuracy of the flowmeasurement itself. Read more
The Disposable Flowmeter is a niche-product of which multiple variants have become available in the market. Diversity in the available solutions is needed, there simply is no universal solution with only advantages. Your application, demands and wishes, determine which type of single use flowmeter is the best match. Read more
The quality of the flowmeter is easily verified by doing a number of repeated measurements and comparing the measured values. A robust measurement concept will prove the multiple readings to be close to each other, there is little to no variance. The instrument then has a high repeatability, which is a positive aspect. Read more
